Our review unit of the SilverStone IceMyst 360 PRO traveled all the way from Chino, California, United States, to our location in Calgary, Alberta, Canada through FedEx Ground shipping. Traveling alongside the SilverStone IceMyst 360 PRO, we also received the SilverStone HSW41 and the SilverStone XED120S. The shipping box had a few dents, but the products inside were in perfect condition. SilverStone has also provided us with the IMF70-ARGB upgrade kit.
The SilverStone IceMyst 360 PRO packaging is split into two sections. In the larger navy blue section, there is the SilverStone logo in the top left corner. On the bottom right, the product name is written with a short description right below it. An image of the cooler is printed near the center. There is also the sTR5 icon on the top right that highlights the coolers' support for AMD Threadripper CPUs. The bottom bronze colored section contains icons to show that the cooler supports the motherboard ARGB software utilized by ASRock, ASUS, MSI, Gigabyte, and BIOSTAR motherboards. The other sides of the packaging display more information about the product.
Pulling from SilverStone's website, we have the following specifications:
SilverStone IceMyst 360 PRO
Water block dimension: 73mm (W) x 65mm (H) x 87mm (D) (2.87" (W) x 2.56" (H) x 3.43" (D))
Water block material: Copper base with plastic body
Radiator dimension: 120mm (W) x 28mm (H) x 396mm (D) (4.72" (W) x 1.1" (H) x 15.59" (D))
Radiator material: Aluminum
Fan dimension: 120mm (W) x 25mm (H) x 120mm (D) (4.72" (W) x 0.98" (H) x 4.72" (D))
Fan speed: 500 ~ 2200 RPM
Fan noise level: 11.3~35.5 dBA
Fan rated Voltage: 12V
Fan max airflow: 83.68 CFM
Fan max air pressure: 4.01 mm/H2O
Fan connector: 4 pin PWM & 4-1 pin ARGB (5V LED)
Pump motor speed: 3,000 ±10% RPM
Pump rated voltage: 12V
Pump rated current: 0.38A
Pump connectors: 2510 - 3 pin
Tube length: 460mm
Tube material: Rubber
SilverStone IMF70 ARGB
Speed: 500 ~ 2,800 RPM
Noise level: 28.2 dBA
Rated fan voltage: 12V
Rated LED voltage: 5V
Rated fan current: 0.1A
Rated LED current: 0.3A
Max airflow: 17.2 CFM
Max air pressure: 2.0mmH2O
Bearing: Hydraulic bearing
Dimension: 73mm (W) x 16mm (H) x 143mm (D) (2.87" (W) x 0.63" (H) x 5.63" (D))
